Install iBoard running boards to enhance your vehicle’s functionality and style. This guide provides a clear, step-by-step process for a successful installation, ensuring durability and proper fitment;
1.1 Overview of the Installation Process
The iBoard running board installation involves several key steps, starting with preparing the necessary tools and hardware. Locate the factory mounting points on your vehicle, ensuring proper alignment. Drill holes if required and secure the mounting brackets tightly. Next, attach the running board to these brackets using the provided bolts and washers. Repeat the process for the driver side to ensure symmetry. Finally, tighten all hardware to the specified torque and inspect the installation for stability and alignment. This process ensures a secure and even fit, enhancing both functionality and aesthetics of your vehicle.
1.2 Importance of Following Instructions
Adhering to the installation instructions is crucial for ensuring a safe and proper fitment of your iBoard running boards. Proper alignment and secure mounting prevent damage to both the boards and your vehicle. Following torque specifications guarantees hardware stability, avoiding loosening over time. Incorrect installation can lead to safety hazards and reduced product lifespan. Always use the provided hardware and tools to maintain warranty validity and performance. By carefully following each step, you ensure a reliable and visually appealing installation that enhances your vehicle’s functionality and aesthetic appeal for years to come.
Pre-Installation Preparation
Gather all tools, hardware, and ensure the vehicle is on level ground. Secure the vehicle and wear protective gear before starting the installation process.
2.1 Tools and Hardware Required
To install iBoard running boards, you’ll need tools like a socket wrench, torque wrench, and Allen keys. Hardware includes M6x1-20mm bolts, M8x1.25-35mm carriage bolts, and flat washers. Ensure all parts are included in the kit. Torque specifications range from 6-7 ft-lbs for 6mm bolts to 31-32 ft-lbs for 10mm bolts. Additional tools may include pliers, a rubber mallet, and a drill for certain models. Refer to the installation manual for exact hardware quantities and compatibility with your vehicle’s make and model.
2.2 Safety Precautions
Always wear protective gloves and eyewear during installation. Ensure the vehicle is on level ground and in park with the emergency brake engaged. Avoid over-tightening hardware to prevent damage. Never slide the running board on brackets, as this can cause damage. Use mild soap and non-abrasive products for cleaning to protect the boards. Periodically inspect all bolts and washers to ensure they remain secure. If unsure about any step, consult a professional. Follow torque specifications carefully to avoid stripping threads or over-stressing components.
Mounting Bracket Installation
Locate the factory mounting points and attach the brackets securely. Ensure proper alignment and tighten all bolts according to torque specifications for a stable installation.
3.1 Locating Factory Mounting Points
Start by identifying the factory mounting points on your vehicle. These are typically located along the bottom and inner side of the body panel. For most vehicles, there are three or four mounting locations, depending on the model. Refer to your vehicle’s specifications or the installation manual to confirm the exact positions. Ensure the area is clean and free of debris before proceeding. Once located, remove any rubber plugs or covers from the mounting holes to access the bolts. Proper alignment is crucial, so double-check the positions before drilling or securing the brackets. Always follow the manufacturer’s guidelines to avoid damaging the vehicle’s frame or body.
3.2 Drilling and Securing Brackets
Once the factory mounting points are located, position the mounting brackets accordingly. If drilling is required, use a drill bit that matches the bolt size specified in the instructions. Ensure the brackets are flush against the vehicle’s frame and aligned properly. Secure the brackets using the provided hardware, such as M10 bolts and washers. Tighten the bolts firmly but avoid overtightening, which could damage the vehicle’s frame. Double-check the alignment and ensure all brackets are evenly spaced and securely fastened before proceeding to the next step. Properly secured brackets are essential for the stability and longevity of the running boards.
Running Board Attachment
Slip the M6x1-20mm bolts into the running board’s bottom channel, then carefully position it onto the mounting brackets. Secure tightly without sliding to avoid damage.
4.1 Aligning the Running Board
Align the running board with the mounting brackets, ensuring it fits snugly. Proper alignment prevents damage and ensures stability. Use the factory mounting locations as a guide for accurate positioning. This step is crucial for a secure and even installation, ensuring the running board functions as intended and maintains the vehicle’s aesthetic appeal. Misalignment can lead to improper fitment and potential damage during use. Take your time to ensure the board is correctly positioned before securing it with the provided hardware.
4.2 Securing the Running Board
Once aligned, secure the running board to the mounting brackets using the provided M6x1-20mm bolts, washers, and nylon lock nuts. Insert the bolts through the bottom channel of the board and into the brackets. Tighten each bolt evenly to avoid misalignment. Ensure the board is flush against the brackets and does not slide. Use a torque wrench to tighten to the specified torque (16-18 ft-lbs for M6 bolts). Properly securing the running board ensures stability and prevents damage. Double-check all hardware for tightness before finalizing the installation.
Hardware Tightening
Tighten all bolts, washers, and nylon lock nuts using a torque wrench. Ensure M6x1-20mm bolts are tightened to 16-18 ft-lbs for secure and stable installation.
5.1 Bolt and Washer Assembly
Begin by slipping M6x1-20mm square head bolts into the bottom channel of the running board. Ensure each bolt is properly seated and aligned with the mounting brackets. Attach the running board to the brackets using the provided M6 large flat washers and nylon lock nuts. Tighten each bolt securely, but avoid overtightening to prevent damage. Use a torque wrench to ensure bolts are tightened to the specified torque of 16-18 ft-lbs. This step ensures a stable and durable connection between the running board and the vehicle, providing a safe and secure installation.
5.2 Torque Specifications
Ensure all bolts are tightened to the specified torque to guarantee a secure installation. For M6 bolts, apply 16-18 ft-lbs of torque, while M8 bolts require 31-32 ft-lbs. Larger bolts, such as M10, need 92-94 ft-lbs. Use a torque wrench to achieve precise tightening, avoiding over-tightening, which can damage components. Refer to the hardware list for specific bolt sizes and their corresponding torque values. Proper torque ensures the running board is firmly attached and withstands normal use. Double-check all bolts after tightening to confirm they meet the required specifications for a safe and reliable installation.
Repeat for the Driver Side
Repeat the installation process for the driver side by mirroring the steps completed on the passenger side to ensure symmetry and complete the installation successfully.
6.1 Mirroring the Passenger Side Installation
Mirror the passenger side installation for the driver side to maintain symmetry. Use the same tools and hardware, ensuring brackets align with factory mounting points. Measure distances from edges or reference points to replicate positions accurately. Install the same number and type of bolts and washers as the passenger side for consistency and safety. Align the running board snugly with brackets to prevent crookedness or wobbling. Tighten hardware to specified torque to avoid loose or stripped bolts. Double-check for any vehicle asymmetry and adjust if necessary. Ensure all steps are followed carefully for a secure and even installation. Conduct a final inspection to confirm alignment and stability before testing.
6.2 Ensuring Symmetry
Ensuring symmetry is crucial for both functionality and visual appeal; After mirroring the passenger side installation, measure distances from edges or reference points to confirm alignment. Visually inspect the running boards to ensure they are evenly spaced and level. Check that all hardware is evenly tightened and that the boards do not wobble or tilt. If necessary, adjust the brackets slightly to achieve perfect symmetry. Verify that the running boards align with the vehicle’s body lines for a seamless look. Proper alignment ensures even weight distribution and prevents uneven wear. A symmetrical installation enhances the vehicle’s appearance and ensures optimal performance of the running boards.
Final Inspection
After installation, inspect all hardware to ensure it is securely tightened and properly aligned. Verify that the running boards are evenly positioned and visually appealing. Check for any loose bolts or washers and confirm that the boards do not wobble or tilt; Ensure the installation appears clean and professional, with all components correctly fitted. This final check guarantees safety, durability, and a polished finish.
7.1 Checking All Hardware
7.2 Verifying Proper Alignment
After securing the hardware, visually inspect the running board to ensure it is evenly aligned with the vehicle’s body. Check that the board does not touch or rub against any surrounding panels, as this could cause damage. Verify that the running board is parallel to the ground and properly centered over the mounting brackets. If necessary, adjust the brackets slightly to achieve the correct alignment. Misalignment can lead to uneven wear or functional issues. Use a level tool if available to confirm proper positioning. Ensure the running board is flush with the factory mounting points for a seamless integration and optimal performance.
Maintenance and Care
Regularly clean the running boards with mild soap and water to prevent dirt buildup. Inspect hardware periodically for tightness and signs of wear. Protect the boards from harsh chemicals and scratches for longevity.
8.1 Cleaning Recommendations
Regularly clean your iBoard running boards using mild soap and water to maintain their appearance and durability. Avoid high-pressure washes, as they may damage the surface. Use a soft cloth or sponge to gently scrub away dirt and grime, ensuring no abrasive materials are used. Rinse thoroughly with clean water to remove soap residue. For tougher stains, mix a mild detergent with warm water and apply lightly. Avoid harsh chemicals, bleach, or abrasive cleaners, as they can damage the finish. Dry the boards with a clean towel to prevent water spots. This routine will keep your running boards looking new and functional for years.
8.2 Periodic Inspections
Regularly inspect your iBoard running boards to ensure they remain secure and functional. Check all bolts and brackets for tightness, as they may loosen over time due to vibration or usage. Inspect the boards for any signs of damage, such as dents, scratches, or wear on the surface. Verify that the alignment remains consistent and that no shifting has occurred. Address any issues promptly to prevent further damage or safety hazards. Repeat this process after extreme weather conditions or off-road use to maintain optimal performance and longevity of your running boards.
